مقالات دوربین مداربسته پاناسونیک
معرفی و توضیح در مورد دوربین مداربسته پاناسونیک
مقالات دوربین مداربسته پاناسونیک
معرفی و توضیح در مورد دوربین مداربسته پاناسونیکدوربین مداربسته پاناسونیک WV-SW314
دوربین مداربسته پاناسونیک WV-SW314
•720p HD images up to 30 fps
•Newly developed 1.3 Megapixel high sensitivity MOS Sensor
•Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by “UniPhier®”, Panasonic’s proprietary System LSI platfor
•Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
•Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared to conventional cameras.
•Face Super Dynamic Range technology ensures clear images of the face.
•High sensitivity with Day/Night (Electrical) function: 0.3 lx (Color), 0.2 lx (B/W) at F1.3 (Wide)
•VIQS (Variable Image Quality on Specified area) technology allows the designated area to retain higher image quality while the excluded area will have a decreased image quality, which enables to use lower image file size and bit rate.
•Up to 7.2x Extra Optical Zoom under VGA resolution. 2.8-10 mm, 3.6x vari-focal auto iris lens (5.6-20 mm, 7.2x with Extra Optical Zoom at VGA)
•Face detection function detects the position of human face and the information is sent by XML or video stream.
•Full duplex bi-directional audio allows interactive communication between camera site and monitoring site
•SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure (JPEG)
•Still images (JPEG) can be viewed on mobile phones via Internet.
•ONVIF compliant model
•Analog Monitor output for easier installation
•IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard
•720p HD images up to 30 fps
•Newly developed 1.3 Megapixel high sensitivity MOS Sensor
•Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by “UniPhier®”, Panasonic’s proprietary System LSI platfor
•Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
•Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared to conventional cameras.
•Face Super Dynamic Range technology ensures clear images of the face.
•High sensitivity with Day/Night (Electrical) function: 0.3 lx (Color), 0.2 lx (B/W) at F1.3 (Wide)
•VIQS (Variable Image Quality on Specified area) technology allows the designated area to retain higher image quality while the excluded area will have a decreased image quality, which enables to use lower image file size and bit rate.
•Up to 7.2x Extra Optical Zoom under VGA resolution. 2.8-10 mm, 3.6x vari-focal auto iris lens (5.6-20 mm, 7.2x with Extra Optical Zoom at VGA)
•Face detection function detects the position of human face and the information is sent by XML or video stream.
•Full duplex bi-directional audio allows interactive communication between camera site and monitoring site
•SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure (JPEG)
•Still images (JPEG) can be viewed on mobile phones via Internet.
•ONVIF compliant model
•Analog Monitor output for easier installation
•IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard
ایران پاناسونیک
آدرس سایت:www.iranpanasonic.ir
تلفن: 77615100
آدرس سایت:www.iranpanasonic.ir
تلفن: 77615100
دوربین مداربسته پاناسونیک WV-cp300
دوربین مداربسته پاناسونیک WV-cp300
interline transfer CCD captures NTSC videos at a high resolution up to 650 TVL1/3
2x digital zoom
Minimum illumination of 0.08 lux in color and 0.05 in B/W modes at F/1.4 for low-light surveillance
Privacy masking allows you to mask up to 8 user programmable zones of a scene for privacy reasons
Motion detection feature triggers an alarm in case of any movement in a designated portion of the video display
Lens distortion compensation ensures that the wide angle lens produces distortion-free images
Electronic Shutter helps the camera capture clear images of fast-moving objects
Adaptive Black Stretch technology increases the visibility of subjects in dark areas of a video scene without degrading image quality in the brighter areas
Auto-image stabilization for clear and focused footage even in windy weather conditions
Adaptive Digital Noise Reduction ensures clear images by removing signals that could make video footage grainy
16-axis matrix color compensation for enhanced color adjustment
Electronic light control (ELC) mode for quick lens adjustment upon installation
16-alphanumeric camera title display
Electrical Day/Night function for uninterrupted 24-hour surveillance
Draws power from a 120 VAC power supply
ایران پاناسونیک
آدرس سایت:www.iranpanasonic.ir
تلفن: 77615100
آدرس سایت:www.iranpanasonic.ir
تلفن: 77615100
دوربین مداربسته پاناسونیک WV-SF538
دوربین مداربسته پاناسونیک WV-SF538
High Resolution
(1080p Full HD images up to 30fps)
High Sensitivity Color Reproduction
Face Detection with Super Dynamic Technology
LDC (Lens Distortion Compensation)
Fog and Smoke Reduction
2-area VIQS (Variable Image Quality on Specified Area)
Cropping features
Various Transmission Modes
Smartphone, Tablet PC monitoring*
Advanced Face Detection and Facial Recognition
ایران پاناسونیک
آدرس سایت:www.iranpanasonic.ir
تلفن: 77615100
دوربین مداربسته پاناسونیک WV-SF539
دوربین مداربسته پاناسونیک WV-SF539
• Super high resolution at Full HD/1,920 x 1,080 created by 3.1Megapixel high sensitivity MOS Sensor.
• 1080p Full HD images up to 30 fps and 360p image up to 30fps simultaneously.
• Combining enhanced “UniPhier®”, Panasonic’s proprietary System LSI platform and 2 areas VIQS(Variable Image Quality on Specified area) function can decrease maximum 50%*1 network bandwidth.
• Cropping function enables to provide whole image (1,920 x 1,080) and the part image (640 x 360) simultaneously.Up to 4 image capture areas can be specified, and it is also possible to control the sequence.
• Picture in picture function: A cropping image or an alarm imagecan be added to an image and transmitted.
• Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by enhanced“UniPhier®”.
• Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared to conventional cameras.
• Face Super Dynamic Range technology ensures clear face image.
• High sensitivity with Day & Night (IR) function:0.5 lx (Color), 0.06 lx (B/W) at F1.3 (WV-SF539)
• High sensitivity with Day & Night (Electrical) function:0.5 lx (Color), 0.3 lx (B/W) at F1.3 (WV-SF538)
• Using Panasonic distinctive LDC (Lens Distortion Compensation) function, naturalimage without distortion can be monitored though using wide angle lens.
• ABF (Auto Back Focus) ensures easy installation.
• ABF ensures stable focus in both color and B/W modes. (WV-SF539)
• Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions.
• Progressive scan ensures clear images with less motion blur and no tearing even when the subject is moving.
• Superior color reproduction by primary (RGB) color filter.
• Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
• Selectable light control modes: Outdoor scene / Indoor scene (50 Hz) / Indoor scene (60 Hz) /Fixed electronic shutter Outdoor scene: Electronic shutter and ALC lens iris control areautomatically controlled depending on the mode and luminance level. Indoor scene (50 Hz / 60 Hz): Flicker caused by fluorescent lightning will be automatically compensated. Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter can be selectable
• Super high resolution at Full HD/1,920 x 1,080 created by 3.1Megapixel high sensitivity MOS Sensor.
• 1080p Full HD images up to 30 fps and 360p image up to 30fps simultaneously.
• Combining enhanced “UniPhier®”, Panasonic’s proprietary System LSI platform and 2 areas VIQS(Variable Image Quality on Specified area) function can decrease maximum 50%*1 network bandwidth.
• Cropping function enables to provide whole image (1,920 x 1,080) and the part image (640 x 360) simultaneously.Up to 4 image capture areas can be specified, and it is also possible to control the sequence.
• Picture in picture function: A cropping image or an alarm imagecan be added to an image and transmitted.
• Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by enhanced“UniPhier®”.
• Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared to conventional cameras.
• Face Super Dynamic Range technology ensures clear face image.
• High sensitivity with Day & Night (IR) function:0.5 lx (Color), 0.06 lx (B/W) at F1.3 (WV-SF539)
• High sensitivity with Day & Night (Electrical) function:0.5 lx (Color), 0.3 lx (B/W) at F1.3 (WV-SF538)
• Using Panasonic distinctive LDC (Lens Distortion Compensation) function, naturalimage without distortion can be monitored though using wide angle lens.
• ABF (Auto Back Focus) ensures easy installation.
• ABF ensures stable focus in both color and B/W modes. (WV-SF539)
• Digital Noise Reduction: 3D-DNR ensures noise reduction in various conditions.
• Progressive scan ensures clear images with less motion blur and no tearing even when the subject is moving.
• Superior color reproduction by primary (RGB) color filter.
• Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
• Selectable light control modes: Outdoor scene / Indoor scene (50 Hz) / Indoor scene (60 Hz) /Fixed electronic shutter Outdoor scene: Electronic shutter and ALC lens iris control areautomatically controlled depending on the mode and luminance level. Indoor scene (50 Hz / 60 Hz): Flicker caused by fluorescent lightning will be automatically compensated. Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter can be selectable
ایران پاناسونیک
آدرس سایت:www.iranpanasonic.irتلفن: 77615100
دوربین مداربسته پاناسونیک WV-SF548
دوربین مداربسته پاناسونیک WV-SF548
•Dome Camera
•Lens: Vari Focal Auto Iris
•Image Sensor Type: 1/3 type MOS Sensor
•Zoom Capability: 3.6x (8.4 mm - 30 mm 10.8x with Extra optical zoom at 360P)
•Resolution: 1920x1080 - 320x180
•Power Requirement: PoE (IEEE 802.3af)/ 12V DC
•Indoor (14 °F ~ 122 °F)
•Vandal Proof: Yes
•Focal Length: f=2.8 mm - 10 mm
•Compression format: H.264, MPEG-4, MJPEG
•Audio: No
•Software Included
•ONVIF
•Dome Camera
•Lens: Vari Focal Auto Iris
•Image Sensor Type: 1/3 type MOS Sensor
•Zoom Capability: 3.6x (8.4 mm - 30 mm 10.8x with Extra optical zoom at 360P)
•Resolution: 1920x1080 - 320x180
•Power Requirement: PoE (IEEE 802.3af)/ 12V DC
•Indoor (14 °F ~ 122 °F)
•Vandal Proof: Yes
•Focal Length: f=2.8 mm - 10 mm
•Compression format: H.264, MPEG-4, MJPEG
•Audio: No
•Software Included
•ONVIF
ایران پاناسونیک
آدرس سایت:www.iranpanasonic.irتلفن: 77615100
